REWINDING * REPAIR * REPLACEMENT * CUSTOM BUILDS
P-90
Pickup OHMS are approximate as pickups are handwound when ordered. Some pickups here can be altered to customers needs- including wire gauge, magnet type, color, string spacing and hook up leads.
Email us
Free shipping within the USA if yours
is international order please email
us at sentellpickups@gmail.com for
shipping prices to your country.
A03
P-90 Soapbar
8.5K ohms
42 AWG
Two Alnico V magnets
south to strings
Single conductor braided
ground wire
Handwound / Wax Potted
Black, white or cream cover
$90.00
A14
A14N
P-90 SIDEWOUND HUMBUCKER
Two coil humbucking system
Strat-like tone
11.6 K 0HMS
43 AWG
Handwound for vintage tone
AL-V rod mags south to strings
50 mm string spread
Two conductor
Mounting screws included
Wax Potted
$105.00 Black or cream cover
$115.00 Nickel plated cover
A21
Frostbite
P-90 HUMBUCKER
Side-wound
Colder than ice
17.5k ohms
Handwound with 43 AWG
50mm or 52mm string spread
Alnico 5 rod magnets
Magnetic polarity south to strings
Fiberboard bobbins
Available with cream or black cover
Four conductor hook-up leads
Mounting screws included
Wax potted
Available with hex head or
fillister head screws
$105.00
A27
A27A
P-90,000
P-90 Staggered Humbucker
11.4k ohms
Alnico V
Single conductor braided groundwire
Handwound / Wax potted
with screws $105.00
or
with Alnico V rod magnets $105.00
A05G
THE GORN
52mm string spread
8.9k ohms
1/4" Alnico V rods
Two conductor hook up leads
Wax potted
Fits and mounts like a P-90
$95.00
A23
BIG RED
Handcrafted clear polycarbonate top
soft iron slugs with an
open faced soapbar P-90 cover
11.9k ohms
Handwound with 42awg
Two massive 1/4"thick Ceramic 8 bar magnets south to strings,
for megatone
Single conductor braided shielded hookup wire
Wax potted
$100.00
A24
SNAKE CHARMER
CLEAR P-90 SIZE HUMBUCKER
Clear Polycarbonate top
and clear nos T-top bobbins
20.3K OHMS
44 AWG
Six Alnico V rod magnets
south to strings
Single conductor braided ground wire
50mm string spread
Handwound / Wax Potted
Black P-90 surround
$105.00
A08
BLADE -9O GUITAR PICKUP
Humcanceling
9.8 K 0HMS
52mm string spread
Hand-wound with 42 awg
Alnico V magnets South to strings
Wax Potted
Mounting screws included
Two conductor hook-up wire
with an extra ground wire
to blade
$105.00
A28
Chem Dog
Humcanceling Blade Pick-up
10.2K OHMS
Alnico V magnets
south to strings
70mm long blade
to accommodate most string spreads
P-90 dogear cover
Handwound / Wax Potted
$105.00
A30
A30
Dogear with screws
8.4k ohms
42 awg
Two Alnico V magnets
south to strings
Single conductor braided ground wire
Extra ground wire to baseplate
Handwound / Wax Potted
P-90 dogear cover
$90.00
A25
Dogbucker Adjustable
For tight spaces between strings and deck
Height adjustable
Fits in P-90 cavity
Alnico V bar magnet
9.3K ohms
42 AWG
12 nickel plated adjustable screws
Single conductor braided ground wire
Humbucker bobbins
Hand-wound / Wax potted
$113.00
A02
DOGBUCKER
50mm string spread
Alnico-5 bar mag
9.3K ohms
42AWG
6 nickel plated adjustable screws
Single conductor braided ground wire
Humbucker bobbins
Hand-wound / Wax Potted
$100.00
A17
Dog Ear
Staggerd Humbucker
10.3 k ohms
43 awg
Six Alnico V rods
Four conductor hookup leads
Prelinked for humcancelling
Handwound
Coils are wax potted inside cover
$90.00
A19
Dogear with Chrome cover
7.3 K ohms
42 AWG
Handwound
Alnico V rod mags
south to strings
Two conductor
Wax Potted
$100.00
